Forklift Fuel Tank - The majority of fuel tanks are fabricated; nevertheless some fuel tanks are made by skilled craftspeople. Custom tanks or restored tanks could be utilized on aircraft, automotive, tractors and motorcycles.
There are a series of specific requirements to be followed when constructing fuel tanks. Typically, the craftsman sets up a mockup to be able to know the correct size and shape of the tank. This is often done making use of foam board. Next, design problems are dealt with, comprising where the outlets, seams, drain, baffles and fluid level indicator would go. The craftsman should determine the alloy, temper and thickness of the metal sheet he would make use of so as to construct the tank. As soon as the metal sheet is cut into the shapes required, many pieces are bent in order to create the basic shell and or the baffles and ends for the fuel tank.
In racecars and aircraft, the baffles contain "lightening" holes, which are flanged holes which provide strength to the baffles, while also reducing the tank's weight. Openings are added toward the ends of construction for the fuel pickup, the filler neck, the fluid-level sending unit and the drain. Every so often these holes are added when the fabrication process is complete, other times they are made on the flat shell.
Afterward, the ends and baffles could be riveted into position. The rivet heads are normally soldered or brazed in order to prevent tank leaks. Ends could after that be hemmed in and flanged and sealed, or brazed, or soldered using an epoxy kind of sealant, or the ends could also be flanged and after that welded. After the welding, soldering and brazing has been completed, the fuel tank is tested for leaks.
